Universal Controller รุ่น N2000



รายละเอียดสินค้า :



• Accepts thermocouples type J, K, T, N, R, S; Pt100 RTD, linear 4-20 mA, 0-50 mV, 0-5 Vdc

• Double LED display: red for PV and green for SV


• Dual SPST 3 A / 250 Vac relays and dual SPDT 5 A / 250 Vac relays can be individually programmed for control or alarm


• Isolated 4-20 mA output with 1500-level resolution, maximum 550 ohm load for control or PV / SV retransmission. It can also be configured for digital input or output (10 Vdc / 20 mA)


• Sampling rate: 4 measurements per second


• One digital input for dry contact with 5 programmable functions


• Remote setpoint input for 4-20 mAdc signal (N2000)


• 24 Vdc / 30 mA supply output for remote transmitter excitation


• RS485 comm with Modbus RTU protocol (optional)


• Auto tuning PID control


• Auto/Manual mode, bumpless transfer


• Programmable Soft start up to 9999 seconds


• Ramp and Soak: 7 programs of up to 7 segments each. Can be linked to create longer programs of up to 49 segments


• Measured value resolution: 12,000 levels


• Control output update: 250 ms


• Up to four configurable relays, two timer alarms


• Alarm functions: LO, HI, differential, differential LO, differential HI, sensor break and event


• Alarm initial blocking function


• Power: 100 to 240 Vac/dc, 50/60 Hz; optional 24 Vdc/ac


• Maximum consumption: 4 VA


• Circuitry can be removed from the front panel


• Operating environment: 0 to 55 ºC, 20 to 90 % RH


• Front panel: IP65, Polycarbonate UL94 V-2


• Back panel: IP30, ABS + PC UL94 V-0


• Dim ensions: 48 x 96 x 92 mm, 1/8 DIN


• Panel cutout: 45.5 x 93 mm


• Weight: 240 g (265 g with options)
