Specification:
►Range : -50 to 600°C (Table 2.1)
►Dial : Alumium, white, black lettering
►Lens : Glass
►Enclosure rating : IP65
►Accuracy : Class 1 according DIN EN 13190 (Ambient temperature ≤ 40°C)
►Material of extension : 304SS
►Connection type : Roatry thread type standard, other availavle (TABLE 2.2)
►Connection : 1/2"PT standard, 1/4"PT, 3/8"PT, 3/4"PT and other available (TABLE 2.3)
►Stem diameter (ød) : ø12 standard, ø6, ø6.35(1/4"), ø8, ø9.5(3/8"), ø10 are available (TABLE 2.3)
►Material of connection and stem : 304SS
►Insertion length (L) : Minimum refers to the TABLE 2.1

Options:
►Dual scale (°C and °F)
►With electrical switch contact (TABLE 2.5)
►External set point adjustment
►Safety glass lens
►316SS connection and stem
►Liquid damping
►External coating
►Stainless steel tag No.
►A wire with PT100Ω signal output
